| Battery Module Energy (kWh) |
16.08 |
| Battery Module Nominal Voltage (V) |
51.2 |
| Battery Module Capacity (Ah) |
314 |
| Module Weight Approximate (kg) |
126 |
| Battery Module Qty In Series (Optional) |
5 ~ 16 |
| System Nominal Voltage (V) |
256 ~ 819.2 |
| System Energy (kWh) |
80.3 ~ 257.2 |
| System Usable Energy (kWh) |
72.27 ~ 231.48 |
| Max.Charge/Discharge Current ( A) |
180 |
| Operating Temperature (°C) |
Charge: 0 – 55; Discharge: -20 – 55 |
| Storage Temperature (°C) |
0 – 35 |
| Thermal Management |
Smart fan cooling |
| LCD Display |
SOC / Fault Code |
| Status Indicator |
Yellow: Battery High Voltage Power On; Red: Battery System Alarm |
| Communication Port |
TCP / RS485 / CAN |
| Communication With BMS |
CAN |
| Humidity |
5% – 85% |
| Altitude |
≤3000m |
| IP Rating of Enclosure |
IP20 |
| Noise (dB) |
TBD |
| System Dimension (W × H × D, mm) |
1067 x 1305 x 800 / 1608 x 1305 x 800 / 2150 x 1305 x 800 |
| System Weight Approximate (kg) |
758 ~ 2240 |
| Installation Location |
Rack Mounted |
| Recommend Depth of Discharge |
90% |
| Cycle Life |
25±2°C, 0.5C / 0.5C, EOL70%≥6000 |
| Warranty Period |
10 years |
| Certification |
CE / IEC62619 / IEC62040 / UN38.3 |
